Planova™ S20N is the next generation regenerated cellulose virus filter that’s ready for any challenges. S20N promises “superior” filtration performance for various types of biotherapeutic products, “secure” robust virus removal capability, and “simplified” operation for your post-use integrity test. We endeavor to contribute to further improvement of operations and the greater safety of biologicals.
Details for Planova S20N
Please refer to the product detail pages for brochure, technical documents, and other materials.
Specifications & Parameters
| Effective surface area (m²) | ||||||||
|---|---|---|---|---|---|---|---|---|
| 4.0 | 1.0 | 0.3 | 0.1 | 0.01 | 0.001 | |||
| Component | Hollow fiber membrane | Cuprammonium regenerated cellulose | ||||||
| Housing and headers | Polycarbonate | |||||||
| Sealant | Polyurethane | |||||||
| O-rings | Silicone | |||||||
| Nozzle plugs | Silicone | - a | ||||||
| Nozzle caps | - | Silicone | ||||||
| Ferrule caps | Polycarbonate | - | ||||||
| Luer lock plugs | - | Polypropylene | ||||||
| Balloon cap holders | Polycarbonate | - | ||||||
| Gaskets b | Silicone | - | ||||||
| Balloon caps | Silicone | - | ||||||
| Nozzle stoppers | - | Silicone | - | |||||
| Clamp bands | Poly-sulfone | - | ||||||
| Threaded Clamps | Clamp bolts | Polypropylene | - | |||||
| Clamp nuts | Polypropylene | - | ||||||
| Lock nuts | Polycarbonate | - | ||||||
| Supplied as | Filled with purifled water c | |||||||
| Sterilization Method | Autoclaving | |||||||
| Packaging Format | Packed individually in sterilized bags | |||||||
| Operating Pressure(TMP) | 216 kPa (31.3psi) | |||||||
| Operating pH | 3-9 | |||||||
| Biological Safety | Conformance with USP standards for class VI plastics | |||||||
a Not applicable
b Gaskets are used for connecting quick clamps to nozzles of Planova S20N filters with effective surface areas of 4.0, 1.0, 0.3 and 0.1 m2
c Purified water in 4.0 m2 Planova S20N filters contains < 0.1% NaCl
b Gaskets are used for connecting quick clamps to nozzles of Planova S20N filters with effective surface areas of 4.0, 1.0, 0.3 and 0.1 m2
c Purified water in 4.0 m2 Planova S20N filters contains < 0.1% NaCl
Ordering information
The table below lists the catalog number for Planova™ S20N virus removal filters.
Please contact us and cite the number below to order.
Please contact us and cite the number below to order.
| Effective Surface Area (m²) | Catalog No. | |
|---|---|---|
| Planova S20N | ||
| 4.0 | S20-LF40 | |
| 1.0 | S20-LF10 | |
| 0.3 | S20-3000 | |
| 0.1 | S20-1000 | |
| 0.01 | S20-0100 | |
| 0.001 | S20-0010 |
